Hybrid Dual Power (Gasoline + Electric)
Dual power system with automatic self-charging during operation.
Stepless Transmission
Fully unmanned control for steering, U-turns, acceleration/deceleration, and spray system activation.
Item | Unit | Parameter | |
Main Unit | Model |
| 3WZ-300L |
Dimensions (L×W×H) | mm | 1950*1000*950 | |
Structural Weight | kg | 700 | |
Crawler Width | mm | 150 | |
Operating Slope | ° | ≤30 | |
Travel Speed | m/min | 0-80 Adjustable | |
Wooden Packaging | Packaging Dimensions | mm | 1970*1020*970 |
Packaging Weight | kg | 50 | |
Drive System | Generator Rated Power | Kw | 5 |
Travel Motor Rated Power | Kw | 1.5*2 | |
Battery Type |
| Dry Cell Battery | |
Battery Capacity | Ah/V | 20Ah*4/48V+60Ah*1/12V | |
Operating Voltage | V | 48 | |
Charging Mode |
| Auto-charging during generator operation | |
Spray System | Engine Model | Changong | CG292F |
Engine Type |
| Twin-cylinder 4-stroke | |
Fuel Type |
| Diesel | |
Average Fuel Consumption | L/h | 2.5-3 | |
Engine Rated Power | Kw | 19.8 | |
Spray Type |
| Air-assisted Spray | |
Nozzle Quantity | pcs | 10 | |
Tank Capacity | L | 300 | |
Single-Side Spray Width | m | 4-5 | |
Pump Model |
| HS-J32 | |
Pump Pressure | Mpa | 3.5-5.0 | |
Pump Speed | rpm | 500-900 | |
Pump Flow Rate | L | 24-43.5 | |
Pump Stroke | Mm | 20 | |
Hybrid Dual Power (Gasoline + Electric)
Dual power system with automatic self-charging during operation.
Stepless Transmission
Fully unmanned control for steering, U-turns, acceleration/deceleration, and spray system activation.
Motor-Driven Agility
Zero-radius turning capability and auto-braking when stopped, powered by efficient motor drive.
Tank-Style Crawler Chassis
Adapts to rugged terrains: mountains, slopes, sandy areas, and uneven ground.
Smart Nozzle System
Individually controlled nozzles with adjustable angles and variable spray volume.
Low-Pressure Elongated Tracks
Reduces ground compaction and enhances traction with extended anti-slip crawler tracks.
100% Unmanned Operation
Eliminates pesticide exposure risks by removing human involvement in hazardous environments.
